API Std 599
Click here to purchase
Covers steel, nickel base and other alloy plug valves with flanged or butt-welding ends and ductile iron plug valves with flanged ends in sizes NPS 1/2 through NPS 36 and threaded or socket-welding ends for sizes NPS 1/2 through NPS 2. This standard also provides additional requirements for plug valves that are in full conformance to the requirements of ASME B16.34 for Standard Class 150 through 2500.
Product Details
- Edition:
- 8th
- Published:
- 03/01/2020
- Number of Pages:
- 26
- File Size:
- 1 file , 820 KB
- Redline File Size:
- 2 files , 4.8 MB
- Product Code(s):
- C59908, C59908, C59908, C59908
- Note:
- This product is unavailable in Cuba, Iran, North Korea, Syria
API Std 599
Click here to purchase
This standard covers steel, nickel base and other alloy plug valves with flanged or butt-welding ends and ductile iron plug valves with flanged ends in sizes NPS 1/2 through NPS 24 and threaded or socket-welding ends for sizes NPS 1/2 through NPS 2. Valve bodies conforming to ASME B16.34 may have one flange and one butt-welding end, or one threaded and one socket welding end.
Product Details
- Edition:
- 6th
- Published:
- 10/01/2007
- ANSI:
- ANSI Approved
- Number of Pages:
- 12
- File Size:
- 1 file , 180 KB
- Product Code(s):
- C59906, C59906, C59906, C59906, C59906, C59906
- Note:
- This product is unavailable in Cuba, Iran, North Korea, Syria
API Std 599
Click here to purchase
This standard covers design, materials, face-to-face dimensions, pressure-temperature ratings, and examination, inspection, and test requirements for metallic plug valves
This standard includes requirements for valves fitted with internal body, plug, and port linings or applied hard facings on the body, body ports, plug, and plug port. The extent of linings and the facing materials of which they are made are not covered in this standard.
This standard also provides additional requirements for plug valves that are in full conformance to the requirements of ASME B16.34 for Standard Class 150 through 2500. Ductile iron valves, Class 150 and 300, shall follow the additional requirements of ASME B16.42 for pressure-temperature ratings, wall thickness, flange dimensions, and material grade.
Plug valves covered in this standard belong to one of four general design groups that in many cases have different face-to-face and end-to-end dimensions. Some types of plug valves are not made to all patterns. The four groups of valve design are described below.
The standard nomenclature for valve parts is shown in Annex B. Figure B.1, Figure B.2, Figure B.3, and Figure B.4 illustrate typical plug valve designs and are not to be construed as precluding other available designs that comply with the requirements of this standard. The only purpose of these figures is to identify part names. The construction of a valve is acceptable only when it complies with this standard in all respects.
Product Details
- Edition:
- 7th
- Published:
- 01/01/2013
- Number of Pages:
- 28
- File Size:
- 1 file , 520 KB
- Product Code(s):
- C59907, C59907, C59907
- Note:
- This product is unavailable in Cuba, Iran, North Korea, Syria
API Std 599
Click here to purchase
A purchase specification that covers requirements for metal plug valves with flanged or butt-welding ends, and ductile iron plug valves with flanged ends, in sizes NPS 1 through NPS 24, which correspond to nominal pipe sizes in ASME B36.10M. Valve bodies conforming to ASME B16.34 may have flanged end and one butt-welding end. It also covers both lubricated and nonlubricated valves that have two-way coaxial ports, and includes requirements for valves fitted with internal body, plug, or port linings or applied hard facings on the body, body ports, plug, or plug port. Pages:
Product Details
- Edition:
- 5th
- Published:
- 08/01/2002
- ANSI:
- ANSI Approved
- Number of Pages:
- 24
- File Size:
- 1 file , 280 KB
- Product Code(s):
- C59905R, C59905, C59905, C59905R, C59905, C59905R
- Note:
- This product is unavailable in Cuba, Iran, North Korea, Syria
