API Std 603
Click here to purchase
This standard specifies the requirements for corrosion-resistant bolted bonnet gate valves meeting the requirements of ASME B16.34, Standard Class, for valves having flanged or butt-weld ends in sizes NPS ½ through 24, corresponding to nominal pipe sizes in ASME B36.10M, and Classes 150, 300, and 600.
This standard covers the requirements for corrosion-resistant gate valves for use in process piping applications. Covered are requirements for outside-screw-and-yoke (OS&Y) valves with rising stems, non-rising hand-wheels, bolted bonnets, and various types of gate configurations.
Product Details
- Edition:
- 9th
- Published:
- 09/01/2018
- Number of Pages:
- 33
- File Size:
- 1 file , 730 KB
- Redline File Size:
- 2 files , 5.2 MB
- Product Code(s):
- C60309, C60309, C60309, C60309, C60309, C60309
- Note:
- This product is unavailable in Cuba, Iran, North Korea, Syria
API Std 603
Click here to purchase
This standard specifies the requirements for corrosion-resistant bolted bonnet gate valves meeting the requirements of Standard Class, ASME B16.34 and having full port openings for use in process piping applications. This standard sets forth the requirements for the following gate valve features:
- bolted bonnet;
- outside screw and yoke;
- rising stems;
- non-rising handwheels;
- single or double gate;
- wedge or parallel sealing;
- metallic seating surfaces;
- flanged or butt-welding ends.
Corresponding to nominal pipe size DN:
15; 20; 25; 32; 40; 50; 65; 80; 100; 150; 200; 250; 300; 350; 400; 450; 500; 600.
It covers valves of the nominal pipe size NPS:
1/2; 3/4; 1; 1 1/4; 1 1/2; 2; 2 1/2; 3; 4; 6; 8; 10; 12; 14; 16; 18; 20; 24.
Applies to pressure class designations:
150; 300; 600.
Annex B illustrates a bolted bonnet gate valve for the purpose of establishing standard nomenclature for valve parts.
Product Details
- Edition:
- 8th
- Published:
- 02/01/2013
- Number of Pages:
- 19
- File Size:
- 1 file , 540 KB
- Redline File Size:
- 2 files , 5.6 MB
- Product Code(s):
- C60308, C60308, C60308, C60308, C60308, C60308
- Note:
- This product is unavailable in Cuba, Iran, North Korea, Syria
API Std 603
Click here to purchase
This Standard specifies the requirements for corrosion-resistant bolted bonnet gate valves meeting the requirements of ASME B16.34, Standard Class, for valves having flanged or butt-weld ends in sizes NPS 1/2 through 24, corresponding to nominal pipe sizes in ASME B36.10M, and Classes 150, 300, and 600.
This Standard covers requirements for corrosion resistant gate valves for use in process piping applications. Covered are requirements for outside-screw-and-yoke (OS&Y) valves with rising stems, non-rising hand-wheels, bolted bonnets, and various types of gate configurations.
Product Details
- Edition:
- 7th
- Published:
- 07/01/2007
- ANSI:
- ANSI Approved
- Number of Pages:
- 12
- File Size:
- 1 file , 400 KB
- Product Code(s):
- C60307R, C60307, C60307, C60307R, C60307R, C60307
- Note:
- This product is unavailable in Cuba, Iran, North Korea, Syria
API Std 603
Click here to purchase
API Standard 603 covers corrosion-resistant bolted bonnet gate valves with flanged or butt-weld ends in sizes NPS 1/2 through 24, corresponding to nominal pipe sizes in ASME B36.10M, and Classes 150, 300, and, 600, as specified in ASME B16.34.
Also included in Standard 603 are requirements for corrosion resistant gate valves for use in process piping applications. Covered are requirements for outside-screw-and-yoke (OS&Y) valves with rising stems, non-rising hand-wheels, bolted bonnets, and various types of gate configurations.
Product Details
- Edition:
- 7th
- Published:
- 04/01/2001
- ANSI:
- ANSI Approved
- Number of Pages:
- 9
- File Size:
- 1 file , 270 KB
- Product Code(s):
- C60306, C60306, C60306
- Note:
- This product is unavailable in Cuba, Iran, North Korea, Syria
