API Std 6DX

September 11, 2020 by No Comments

Click here to purchase
This standard defines the requirements for design, mechanical integrity, and sizing of actuators and related components, and is applicable to all types of electric, pneumatic, and hydraulic actuators, inclusive of mounting kit, installed on valves that conform to API Specification 6D.

This standard applies to actuators that are part-turn, multi-turn, or linear in action. It applies to part-turn actuators capable of withstanding torsional forces, multi-turn actuators capable of withstanding torsional forces and axial thrust, and linear actuators capable of withstanding axial thrust.

This document is not applicable to actuators installed on control valves, valves being used for regulation, valves in subsea service, handheld powered devices, stand-alone manually operated gearboxes, instrument tubing and associated fittings, and actuator control equipment.

Product Details

Edition:
2nd
Published:
02/01/2020
ANSI:
ANSI Approved
Number of Pages:
44
File Size:
1 file , 560 KB
Redline File Size:
2 files , 6.8 MB
Product Code(s):
G6DX02, G6DX02, G6DX02, G6DX02, G6DX02
Note:
This product is unavailable in Cuba, Iran, North Korea, Syria

API Std 6DX

September 11, 2020 by No Comments

Click here to purchase
Please note that any addenda or errata may not be included in translated editions of this standard.

Standard 6DX defines the requirements for mechanical integrity and sizing of actuators used on valves manufactured under ISO 14313 and API Specification 6D.

This International Standard is applicable to all types of electric, pneumatic and hydraulic actuators, inclusive of mounting kit, installed on pipeline valves.

This International Standard is not applicable to actuators installed on control valves, valves being used for regulation, valves in sub-sea service, handheld powered devices, stand-alone manually operated gearboxes, instrument tubing and associated fittings and actuator control equipment.

Product Details

Edition:
1st
Published:
10/01/2012
ANSI:
ANSI Approved
Number of Pages:
63
File Size:
1 file , 1.3 MB
Same As:
ISO 12490:2011
Product Code(s):
GG6DX01, GG6Dx01R, GG6Dx01R, GG6DX01, GG6Dx01R, GG6DX01
Note:
This product is unavailable in Cuba, Iran, North Korea, Syria
