IPC HERMES-9852

March 21, 2023 by No Comments

Click here to purchase

The aim of this specification is to create a state-of-the-art communication protocol for handling board transfers and associated data at surface-mount technology (SMT) production lines. Therefore, this new communication protocol has to cope with the following:
• Replace the electrical SMEMA interface as specified in IPC-SMEMA-9851
• Extend the interface to communicate:
    – Unique identifiers for the handled printed circuit boards (PCBs)
    – Equipment identifiers of the first machine noticing a PCB
    – Barcodes
    – Conveyor speed and intended board route
    – A lightweight digital twin of the product containing, e.g.,
▪ Product type identifier
▪ Length
▪ Width
▪ Thickness
▪ Board state

With respect to version numbers The Hermes Standard adheres to the rules of Semantic Versioning 2.0.0 [SemVer_2.0.0].

Hints on naming:
• Wherever a feature is described by the word “shall” it is mandatory.
• The word “machine” is used for any equipment which can be found in a SMT production line (e.g., printers, placement machines, ovens, AOIs, transport modules, shuttles, stackers).
• The term “PCB” may also refer to carriers transporting PCBs.
• The word “Hermes” is used as abbreviation for “The Hermes Standard”.
• “The Hermes Standard” and IPC-HERMES-9852 are synonyms for the standard specified in this document and might be used interchangeably.

Product Details

Published:
11/01/2022
ISBN(s):
9781638161141
Number of Pages:
64
File Size:
1 file , 3.9 MB
Note:
This product is unavailable in Russia, Ukraine, Belarus

IPC HERMES-9852

May 4, 2022 by No Comments

Click here to purchase

The aim of this specification is to create a state-of-the-art communication protocol for surface-mount technology (SMT) production lines. Therefore, this new communication protocol has to cope with the following:
– Replace the electrical SMEMA interface as specified in IPC-SMEMA-9851
– Extend the interface to communicate:
   Unique identifiers for the handled printed circuit boards (PCBs)
   Equipment identifiers of the first machine noticing a PCB
   Barcodes
   Conveyor speed
   Product type specific information:
       Product type identifier
       Length
       Width
       Thickness
       . . .

With respect to version numbers The Hermes Standard adheres to the rules of Semantic Versioning 2.0.0 [SemVer_2.0.0].

Hints on naming:
– Wherever a feature is described by the word “shall” it is mandatory.
– The word “machine” is used for any equipment which can be found in a SMT production line (e.g., printers, placement machines, ovens, AOIs, transport modules, shuttles, stackers).
– The term “PCB” may also refer to carriers transporting PCBs.
– The word “Hermes” is used as abbreviation for “The Hermes Standard”.
– “The Hermes Standard” and IPC-HERMES-9852 are synonyms for the standard specified in this document and might be used interchangeably.





Product Details

Edition:
1.4
Published:
02/01/2022
ISBN(s):
9781638160632
Number of Pages:
64
File Size:
1 file , 3.7 MB
Product Code(s):
9852-STD-0-D-4-EN-0, 9852-STD-0-D-4-EN-0
Note:
This product is unavailable in Belarus, Russia, Ukraine

IPC HERMES-9852

September 11, 2020 by No Comments

Click here to purchase
The aim of IPC HERMES-9852 is to create a state-of-the-art communication protocol for surface-mount technology (SMT) production lines. Therefore, this new communication protocol has to cope with the following:

  • Replace the electrical SMEMA interface as specified in IPC-SMEMA-9851
  • Extend the interface to communicate (including):
    • Unique identifiers (IDs) for the handled printed boards
    • Equipment identifiers of the first machine noticing a printed board
    • Barcodes
    • Conveyor speed
    • Product type specific information (including):
      • Product type identifier
      • Length
      • Width
      • Thickness

With respect to version numbers IPC-HERMES-9852 adheres to the rules of Semantic Versioning 2.0.0 (SemVer_2.0.0).

Product Details

Edition:
1.2
Published:
06/01/2019
ISBN(s):
9781951577018
Number of Pages:
52
File Size:
1 file , 6 MB
Product Code(s):
9852-STD-0-D-0-CN-0
